GRADE CONTROL FOR MOTOR GRADERS

Leave a finished grade the first time, every time.

Mastless motor grader

Eliminate masts and cables traditionally located on the blade for maximum range of motion needed for steep slopes and complex designs. This configuration—available only on select machines—decreases the risk of damage to the machine, keeps valuable antennas safer and reduces the time needed to remove and reinstall them each day.

Make more progress & fewer waves

Trimble Earthworks Grade Control Platform helps operators of all levels leave a quality surface in their tracks. Trimble Earthworks for motor graders is more than future forward. It’s fast forward. The next generation system gives you a first-pass finish that’s second to none. Trimble Earthworks is now available in a subscription model with flexible terms to modernize your equipment with no large upfront cost.

Trimble Earthworks Solutions

See how Trimble can help you work smarter, faster and more profitably with a portfolio of integrated solutions.

Trible Earthworks Software

Trimble Earthworks for Motor Graders is an entirely new grade control software application that is intuitive, easy-to-learn and runs on the Android operating system.

Trimble Earthworks Dual GNSS

Trimble, a leader in precision measurement technology, pioneered the Dual GNSS solution to meet the needs of the construction industry.

3D grade control for motor graders

Trimble 3D grade control can be installed on motor graders to put the site plan – design surfaces, grades and alignments – inside the cab.

Grading

  • Accurately measure the position and blade slope with the single GNSS antenna configuration
  • Measure the exact position, cross slope and the heading of the blade with dual GNSS

Finished Grade

  • Achieve finished grade to millimeter accuracy with fewer passes
  • Place finished grade materials more accurately and in a shorter time period, keeping material costs to a minimum and realizing better profits


Earthworks Brochure


Grade Control Datasheet
